Max Jax lifts are on sale until the 31st of this month for $1939 with free shipping. I think I am going to order one. With the low head height I have in my work garage I think its a good fit. Was wondering does anyone know if they are less anywhere and if you have one how do you like it.
Rodney


______________

Rod, I could see that lift somewhere in my future. That's neat!!

 Didn't pay that much for mine. Bout 15, and had a near home delivery for 125.00.  I can lock mine at different heights and walk under it.

______________

Click on image for full view

I have a four post from Superlifts, the SR-7H. They will deliver and install your lift for a fee. Stay away from the economy lifts that cost around 1,100.00. The steel in these lifts are made from recycled steel from overseas.  I have seen these lifts flex.

Hey Bob, Good to hear from you. How you doin. I almost have to go with a max jax for here at home because of ceiling height. I plan on getting a 4 post for my dads garage where I store mine for the winter. That way He can store my car and tractors! But thats later this year or next.
Rodney


______________

Ordered the max jax lift today. Was told they are on back order and will probably ship sometime around the beginning of May. Now I have to wait! Im not a patient person but I think I can make it! Ordered the 3" and the 6" adapters so I can go up 51".
Rodney


______________

The lift showed up today. Earlier then they had promised and they didnt call in advance so I could make arrangements to have equipment to unload it. The truck driver was really cool thou. He agreed to take it to my lane at home where I got the JD with the front end loader and unloaded it and put it in the garage. Now later next week I will take it out to the shed so I can attempt to get it installed. I really wasnt ready for it but Im glad its here.
Rodney


______________

Always good to get a new toy, Rodney! I wish I could get one but that will have to be in the future!

______________
"Down on the Boardwalk...

(Click image to see a larger version}

Well, I have the lift posts laid out where I would like to put them. I am trying to save as much space as possible so I can put the other vette in the garage beside the lift. Now as I said in another post my shed that I have now used to be a 12 x 18 shed and I expanded to a 20 x 24 shed. When I did this i added concrete on each side of the original pad in a 3 x 18 section and in the rear a 6 x 20 section. My lift will be going on the original pad that was 12 x 18. Plenty big enough and it leaves 72" on the side to the wall. The vette is only 69" wide so I can have one on the lift as the other one is being stored if needed. In order to do this I am going about 4" narrower on my posts. I took a pics of the lift in place with the arms set under the car, pic 1
this shows both arms under the car. The only concern I have is the position of the front leg. It will be on the frame area that is turning in and up on the car. As you can see I Plan on using a 6" pad on front and 3" pad on rear. This should level the car very close normal.
pic 2 which is a total of 6" front lift and a 3" rear leg pic 3
I have enough spacing between the body and the inside of the post at 10" per side. It allows the doors to open 2/3's of the way which is plenty to get in and out of. I will not be able to work on the interior with doors opened and posts in place but that is the beauty of the lift as the posts are very portable and can be stored when not in use. All this is to save some space to park the second one inside if needed.
Where do you locate the leg pads for your vette? I could move the lift posts back which would allow me to pick up the car further back on the front but I think this should be ok.
What do you guys think?
Thanks
Rodney
rod75152011-06-14 20:26:33

______________

Hi Rodney..good to see the progress..if your lift arms lock when it goes up then it shouldn't matter about the arm being out on the rise of the frame..I have never lifted one up that far but I guess it can be done..I would not want the arm to slip out and fall foward..not much from keeping it from doing so if the arms don't lock.

Rich

______________

My first parade at Carlisle 2010

Rich, you should know that without locks on the lift it would be an OSHA violation. Now I would never have or do anything that wouldnt be OSHA approved! What if they came to my house and did an inspection! Anyway, yes it has locks. Once I get it in the air I plan on putting my jacks stands under it as a safety. The go up 50". Very heavy duty. Im trying to locate a 7/8" hammer drill bit for the anchors. No luck yet. Going to give tri-boro a call. I could move the posts back further but Im trying to save space.
Rodney



______________

Finished up the install tonight. Everything works great. No leaks, plenty of ceiling clearance. I should be able to use my standup trans jack to install the trans in a few weeks. I can have all but 52 inches of clearance underneath!
Vette looks good in the air at home!
Rodney


______________

Great job. I put off buying a lift for a long time but when I finally got the four-post lift setup I was very happy. Everything is better lifted.

______________

Brian - NCM Lifetime Member

73 coupe L48, Flat-top pistons, Performer RPM Heads, Crane Cam and roller rockers, Holley 650 vac sec. Performer intake,
3.55 gear BTO 200-4R trans,
Leather seats, Seatbelt Plus 3point seatbelts, Pioneer CD player
Magnaflow Exhuast System

I didn't know these lifts had locks on the arms..that's good..shouldn't be that hard to lift it then..looks like the arms are equal length also..

Rich

______________

My first parade at Carlisle 2010

Rich, the locks arent what I would call super heavy duty but they lock in place. I'll get some pics posted on Monday night once we're back home. You'll have to take a trip and stop down to check it out. But let me know in advance when you plan on coming. I have to clean up the shed first because right now its embarrassing have much junk is sitting around! Cant wait for this project to end so I can have some space back!
Rodney
